K8s 공부 (1)에서 이어집니다.
Minikube
- 앞서 언급했던 것 처럼, 마스터와 워커 노드를 구성하는데 있어서는 많은 리소스와 환경이 필요함 (2마스터와 3개 이상의 워커 노드...)
- 이는 테스트 하거나, 로컬에서 실험을 하는데 있어서는 부적절함
- 그래서 등장한 것이 Minikube
- 하나의 머신에 하나의 마스터 프로세스와 워커 프로세스를 모두 집어 넣음. docker가 기본으로 설치되어 있음.
- 컴퓨터의 버츄얼 박스 등 가상 머신에서 실행됨.
- 1 node K8s cluster
- 테스트 용도로 사용됨.
Kubectl
- pod를 만들고, 다양한 컴포넌트를 만들기 위한 도구
- 마스터 프로세스의 Api server가 실제 클러스터와 상호작용할 수 있는 유일한 창구
- 따라서 무언가를 하기 위해서는, Api Server를 통해야 함.
- 이 Apiserver를 사용할 수 있는 것이 kubectl
- 가장 강력한 도구로, 무엇이든 할 수가 있음.
KubeCtl은 minikube 뿐만 아니라 실제 프로덕션 K8s에서도 사용할 수 있음.
설치 및 사용
https://minikube.sigs.k8s.io/docs/start/ 링크에서 가능. 그러나 앞에서 언급했듯, 가상화 환경이 필요하기 때문에 Virtual Box 등도 설치해야 한다.
> brew update
> brew install hyperkit
> brew install minikube
» kubectl
kubectl controls the Kubernetes cluster manager.
Find more information at: https://kubernetes.io/docs/reference/kubectl/overview/
Basic Commands (Beginner):
create Create a resource from a file or from stdin.
expose Take a replication controller, service, deployment or pod and expose it as a new Kubernetes Service
run Run a particular image on the cluster
set Set specific features on objects
Basic Commands (Intermediate):
explain Documentation of resources
get Display one or many resources
edit Edit a resource on the server
delete Delete resources by filenames, stdin, resources and names, or by resources and label selector
Deploy Commands:
rollout Manage the rollout of a resource
scale Set a new size for a Deployment, ReplicaSet or Replication Controller
autoscale Auto-scale a Deployment, ReplicaSet, StatefulSet, or ReplicationController
Cluster Management Commands:
certificate Modify certificate resources.
cluster-info Display cluster info
top Display Resource (CPU/Memory) usage.
cordon Mark node as unschedulable
uncordon Mark node as schedulable
drain Drain node in preparation for maintenance
taint Update the taints on one or more nodes
Troubleshooting and Debugging Commands:
describe Show details of a specific resource or group of resources
logs Print the logs for a container in a pod
attach Attach to a running container
exec Execute a command in a container
port-forward Forward one or more local ports to a pod
proxy Run a proxy to the Kubernetes API server
cp Copy files and directories to and from containers.
auth Inspect authorization
debug Create debugging sessions for troubleshooting workloads and nodes
Advanced Commands:
diff Diff live version against would-be applied version
apply Apply a configuration to a resource by filename or stdin
patch Update field(s) of a resource
replace Replace a resource by filename or stdin
wait Experimental: Wait for a specific condition on one or many resources.
kustomize Build a kustomization target from a directory or URL.
Settings Commands:
label Update the labels on a resource
annotate Update the annotations on a resource
completion Output shell completion code for the specified shell (bash or zsh)
Other Commands:
api-resources Print the supported API resources on the server
api-versions Print the supported API versions on the server, in the form of "group/version"
config Modify kubeconfig files
plugin Provides utilities for interacting with plugins.
version Print the client and server version information
Usage:
kubectl [flags] [options]
Use "kubectl <command> --help" for more information about a given command.
Use "kubectl options" for a list of global command-line options (applies to all commands).
» minikube
minikube provisions and manages local Kubernetes clusters optimized for development workflows.
Basic Commands:
start Starts a local Kubernetes cluster
status Gets the status of a local Kubernetes cluster
stop Stops a running local Kubernetes cluster
delete Deletes a local Kubernetes cluster
dashboard Access the Kubernetes dashboard running within the minikube cluster
pause pause Kubernetes
unpause unpause Kubernetes
Images Commands:
docker-env Configure environment to use minikube's Docker daemon
podman-env Configure environment to use minikube's Podman service
cache Add, delete, or push a local image into minikube
image Manage images
Configuration and Management Commands:
addons Enable or disable a minikube addon
config Modify persistent configuration values
profile Get or list the current profiles (clusters)
update-context Update kubeconfig in case of an IP or port change
Networking and Connectivity Commands:
service Returns a URL to connect to a service
tunnel Connect to LoadBalancer services
Advanced Commands:
mount Mounts the specified directory into minikube
ssh Log into the minikube environment (for debugging)
kubectl Run a kubectl binary matching the cluster version
node Add, remove, or list additional nodes
cp Copy the specified file into minikube
Troubleshooting Commands:
ssh-key Retrieve the ssh identity key path of the specified node
ssh-host Retrieve the ssh host key of the specified node
ip Retrieves the IP address of the specified node
logs Returns logs to debug a local Kubernetes cluster
update-check Print current and latest version number
version Print the version of minikube
Other Commands:
completion Generate command completion for a shell
Use "minikube <command> --help" for more information about a given command.
모두 정상적으로 설치된 것을 볼 수 있다.
minikube 생성해보기
» minikube start --vm-driver=hyperkit
😄 minikube v1.20.0 on Darwin 11.4
✨ Using the hyperkit driver based on existing profile
👍 Starting control plane node minikube in cluster minikube
🏃 Updating the running hyperkit "minikube" VM ...
🐳 Preparing Kubernetes v1.20.2 on Docker 20.10.6 ...
🔎 Verifying Kubernetes components...
▪ Using image gcr.io/k8s-minikube/storage-provisioner:v5
🌟 Enabled addons: storage-provisioner, default-storageclass
🏄 Done! kubectl is now configured to use "minikube" cluster and "default" namespace by default
» kubectl get nodes
NAME STATUS ROLES AGE VERSION
minikube Ready control-plane,master 2m16s v1.20.2
» minikube status
minikube
type: Control Plane
host: Running
kubelet: Running
apiserver: Running
kubeconfig: Configured
» kubectl version
Client Version: version.Info{Major:"1", Minor:"21", GitVersion:"v1.21.0", GitCommit:"cb303e613a121a29364f75cc67d3d580833a7479", GitTreeState:"clean", BuildDate:"2021-04-08T21:16:14Z", GoVersion:"go1.16.3", Compiler:"gc", Platform:"darwin/amd64"}
Server Version: version.Info{Major:"1", Minor:"20", GitVersion:"v1.20.2", GitCommit:"faecb196815e248d3ecfb03c680a4507229c2a56", GitTreeState:"clean", BuildDate:"2021-01-13T13:20:00Z", GoVersion:"go1.15.5", Compiler:"gc", Platform:"linux/amd64"}
Kubectl의 주요 커맨드 알아보기
생성과 수정
» kubectl get nodes
NAME STATUS ROLES AGE VERSION
minikube Ready control-plane,master 4m26s v1.20.2
» kubectl get pod
No resources found in default namespace.
» kubectl get services
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 4m46s
pod 생성하기?
- pod는 가장 작은 단위
- pod를 직접적으로 만들지는 않음
- 앞서 설명했듯, deployment를 활용해서 추상화를 통해서 많음
» kubectl create deployment nginx-depl --image=nginx
deployment.apps/nginx-depl created
» kubectl get deployment
NAME READY UP-TO-DATE AVAILABLE AGE
nginx-depl 1/1 1 1 26s
» kubectl get pod
NAME READY STATUS RESTARTS AGE
nginx-depl-5c8bf76b5b-fk5b9 1/1 Running 0 39s
- deployment에는 pod를 생성하기 위한 모든 정보가 들어가 있음.
kubectl create deployment nginx-depl --image=nginx를 통해서, 가장 기초적인 설정 (deployment명과 이미지명nginx)으로 deployment를 생성함.- 나머지는 모두 기본값을 설정함.
» kubectl get replicaset
NAME DESIRED CURRENT READY AGE
nginx-depl-5c8bf76b5b 1 1 1 2m41s
Replicaset은 pod의 복제본을 관리하는 역할을 담당하고 있음. 절댜로 수동으로 추가하거나, 삭제하는 것이 아님. deployment의 설정을 통해서 모든 것이 자동으로 이루어지는 것이다.
위에서 보는 것처럼, 1pod와 1replica가 생성된 것을 볼 수 있음.
Deployment는ReplicaSet을 관리하고ReplicaSet은 pod의 모든 복제본을 관리하고Pod는 컨테이너의 추상화를 담당하고 있음.- 그리고 그외의 모든 하위 단계는 자동으로 K8s에 의해 관리되고 있음.
» kubectl edit deployment nginx-depl
자동으로 생성된 설정 파일을 볼 수 있음.
# Please edit the object below. Lines beginning with a '#' will be ignored,
# and an empty file will abort the edit. If an error occurs while saving this file will be
# reopened with the relevant failures.
#
apiVersion: apps/v1
kind: Deployment
metadata:
annotations:
deployment.kubernetes.io/revision: "1"
creationTimestamp: "2021-06-10T14:08:04Z"
generation: 1
labels:
app: nginx-depl
name: nginx-depl
namespace: default
resourceVersion: "744"
uid: 02fd65f5-7170-408a-bc98-1aa735b835ce
spec:
progressDeadlineSeconds: 600
replicas: 1
revisionHistoryLimit: 10
selector:
matchLabels:
app: nginx-depl
strategy:
rollingUpdate:
maxSurge: 25%
maxUnavailable: 25%
type: RollingUpdate
template:
metadata:
creationTimestamp: null
labels:
app: nginx-depl
spec:
containers:
- image: nginx # 이거 뒤에 :1.16을 붙이고 저장해보자.
imagePullPolicy: Always
name: nginx
resources: {}
terminationMessagePath: /dev/termination-log
terminationMessagePolicy: File
dnsPolicy: ClusterFirst
restartPolicy: Always
schedulerName: default-scheduler
securityContext: {}
terminationGracePeriodSeconds: 30
terminationMessagePath: /dev/termination-log
terminationMessagePolicy: File
dnsPolicy: ClusterFirst
restartPolicy: Always
schedulerName: default-scheduler
securityContext: {}
terminationGracePeriodSeconds: 30
status:
availableReplicas: 1
conditions:
- lastTransitionTime: "2021-06-10T14:08:26Z"
lastUpdateTime: "2021-06-10T14:08:26Z"
message: Deployment has minimum availability.
reason: MinimumReplicasAvailable
status: "True"
type: Available
- lastTransitionTime: "2021-06-10T14:08:04Z"
lastUpdateTime: "2021-06-10T14:08:26Z"
message: ReplicaSet "nginx-depl-5c8bf76b5b" has successfully progressed.
reason: NewReplicaSetAvailable
status: "True"
type: Progressing
observedGeneration: 1
readyReplicas: 1
replicas: 1
updatedReplicas: 1
» kubectl get replicaset
NAME DESIRED CURRENT READY AGE
nginx-depl-5c8bf76b5b 0 0 0 10m
nginx-depl-7fc44fc5d4 1 1 1 70s
디버깅
» kubectl get pod
NAME READY STATUS RESTARTS AGE
nginx-depl-7fc44fc5d4-wmh8z 1/1 Running 0 2m42s
~
» kubectl logs nginx-depl-7fc44fc5d4-wmh8z
~
nginx에 뭐 들어온게 없어서 로그가 하나도 안찍혀있다.
» kubectl create deployment mongo-depl --image=mongo
deployment.apps/mongo-depl created
~
» kubectl get pod
NAME READY STATUS RESTARTS AGE
mongo-depl-5fd6b7d4b4-tvzt6 0/1 ContainerCreating 0 6s
nginx-depl-7fc44fc5d4-wmh8z 1/1 Running 0 4m32s
» kubectl describe pod mongo-depl-5fd6b7d4b4-tvzt6
Name: mongo-depl-5fd6b7d4b4-tvzt6
Namespace: default
Priority: 0
Node: minikube/192.168.64.3
Start Time: Thu, 10 Jun 2021 23:21:28 +0900
Labels: app=mongo-depl
pod-template-hash=5fd6b7d4b4
Annotations: <none>
Status: Running
IP: 172.17.0.3
IPs:
IP: 172.17.0.3
Controlled By: ReplicaSet/mongo-depl-5fd6b7d4b4
Containers:
mongo:
Container ID: docker://7d8341691a7e94d0992d0d8b2c2a4bab70820c4c1fcd730a86bb2bcc19cb0950
Image: mongo
Image ID: docker-pullable://mongo@sha256:419ee9e6676031a18186f20f6bcebb2c0a52cb386502293563dc7ff2968a1b89
Port: <none>
Host Port: <none>
State: Running
Started: Thu, 10 Jun 2021 23:22:06 +0900
Ready: True
Restart Count: 0
Environment: <none>
Mounts:
/var/run/secrets/kubernetes.io/serviceaccount from default-token-tffzh (ro)
Conditions:
Type Status
Initialized True
Ready True
ContainersReady True
PodScheduled True
Volumes:
default-token-tffzh:
Type: Secret (a volume populated by a Secret)
SecretName: default-token-tffzh
Optional: false
QoS Class: BestEffort
Node-Selectors: <none>
Tolerations: node.kubernetes.io/not-ready:NoExecute op=Exists for 300s
node.kubernetes.io/unreachable:NoExecute op=Exists for 300s
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal Scheduled 74s default-scheduler Successfully assigned default/mongo-depl-5fd6b7d4b4-tvzt6 to minikube
Normal Pulling 73s kubelet Pulling image "mongo"
Normal Pulled 37s kubelet Successfully pulled image "mongo" in 36.394396367s
Normal Created 37s kubelet Created container mongo
Normal Started 36s kubelet Started container mongo
» kubectl logs mongo-depl-5fd6b7d4b4-tvzt6
{"t":{"$date":"2021-06-10T14:22:06.043+00:00"},"s":"I", "c":"CONTROL", "id":23285, "ctx":"main","msg":"Automatically disabling TLS 1.0, to force-enable TLS 1.0 specify --sslDisabledProtocols 'none'"}
{"t":{"$date":"2021-06-10T14:22:06.046+00:00"},"s":"W", "c":"ASIO", "id":22601, "ctx":"main","msg":"No TransportLayer configured during NetworkInterface startup"}
{"t":{"$date":"2021-06-10T14:22:06.046+00:00"},"s":"I", "c":"NETWORK", "id":4648601, "ctx":"main","msg":"Implicit TCP FastOpen unavailable. If TCP FastOpen is required, set tcpFastOpenServer, tcpFastOpenClient, and tcpFastOpenQueueSize."}
{"t":{"$date":"2021-06-10T14:22:06.046+00:00"},"s":"I", "c":"STORAGE", "id":4615611, "ctx":"initandlisten","msg":"MongoDB starting","attr":{"pid":1,"port":27017,"dbPath":"/data/db","architecture":"64-bit","host":"mongo-depl-5fd6b7d4b4-tvzt6"}}
{"t":{"$date":"2021-06-10T14:22:06.046+00:00"},"s":"I", "c":"CONTROL", "id":23403, "ctx":"initandlisten","msg":"Build Info","attr":{"buildInfo":{"version":"4.4.6","gitVersion":"72e66213c2c3eab37d9358d5e78ad7f5c1d0d0d7","openSSLVersion":"OpenSSL 1.1.1 11 Sep 2018","modules":[],"allocator":"tcmalloc","environment":{"distmod":"ubuntu1804","distarch":"x86_64","target_arch":"x86_64"}}}}
{"t":{"$date":"2021-06-10T14:22:06.046+00:00"},"s":"I", "c":"CONTROL", "id":51765, "ctx":"initandlisten","msg":"Operating System","attr":{"os":{"name":"Ubuntu","version":"18.04"}}}
{"t":{"$date":"2021-06-10T14:22:06.046+00:00"},"s":"I", "c":"CONTROL", "id":21951, "ctx":"initandlisten","msg":"Options set by command line","attr":{"options":{"net":{"bindIp":"*"}}}}
{"t":{"$date":"2021-06-10T14:22:06.047+00:00"},"s":"I", "c":"STORAGE", "id":22297, "ctx":"initandlisten","msg":"Using the XFS filesystem is strongly recommended with the WiredTiger storage engine. See http://dochub.mongodb.org/core/prodnotes-filesystem","tags":["startupWarnings"]}
{"t":{"$date":"2021-06-10T14:22:06.047+00:00"},"s":"I", "c":"STORAGE", "id":22315, "ctx":"initandlisten","msg":"Opening WiredTiger","attr":{"config":"create,cache_size=1409M,session_max=33000,eviction=(threads_min=4,threads_max=4),config_base=false,statistics=(fast),log=(enabled=true,archive=true,path=journal,compressor=snappy),file_manager=(close_idle_time=100000,close_scan_interval=10,close_handle_minimum=250),statistics_log=(wait=0),verbose=[recovery_progress,checkpoint_progress,compact_progress],"}}
{"t":{"$date":"2021-06-10T14:22:06.563+00:00"},"s":"I", "c":"STORAGE", "id":22430, "ctx":"initandlisten","msg":"WiredTiger message","attr":{"message":"[1623334926:563229][1:0x7fc32da96ac0], txn-recover: [WT_VERB_RECOVERY | WT_VERB_RECOVERY_PROGRESS] Set global recovery timestamp: (0, 0)"}}
{"t":{"$date":"2021-06-10T14:22:06.563+00:00"},"s":"I", "c":"STORAGE", "id":22430, "ctx":"initandlisten","msg":"WiredTiger message","attr":{"message":"[1623334926:563299][1:0x7fc32da96ac0], txn-recover: [WT_VERB_RECOVERY | WT_VERB_RECOVERY_PROGRESS] Set global oldest timestamp: (0, 0)"}}
{"t":{"$date":"2021-06-10T14:22:06.569+00:00"},"s":"I", "c":"STORAGE", "id":4795906, "ctx":"initandlisten","msg":"WiredTiger opened","attr":{"durationMillis":522}}
{"t":{"$date":"2021-06-10T14:22:06.569+00:00"},"s":"I", "c":"RECOVERY", "id":23987, "ctx":"initandlisten","msg":"WiredTiger recoveryTimestamp","attr":{"recoveryTimestamp":{"$timestamp":{"t":0,"i":0}}}}
{"t":{"$date":"2021-06-10T14:22:06.577+00:00"},"s":"I", "c":"STORAGE", "id":4366408, "ctx":"initandlisten","msg":"No table logging settings modifications are required for existing WiredTiger tables","attr":{"loggingEnabled":true}}
{"t":{"$date":"2021-06-10T14:22:06.577+00:00"},"s":"I", "c":"STORAGE", "id":22262, "ctx":"initandlisten","msg":"Timestamp monitor starting"}
{"t":{"$date":"2021-06-10T14:22:06.579+00:00"},"s":"W", "c":"CONTROL", "id":22120, "ctx":"initandlisten","msg":"Access control is not enabled for the database. Read and write access to data and configuration is unrestricted","tags":["startupWarnings"]}
{"t":{"$date":"2021-06-10T14:22:06.580+00:00"},"s":"I", "c":"STORAGE", "id":20320, "ctx":"initandlisten","msg":"createCollection","attr":{"namespace":"admin.system.version","uuidDisposition":"provided","uuid":{"uuid":{"$uuid":"782b81b2-5b7e-4f69-9e3e-bf5deed7e4d1"}},"options":{"uuid":{"$uuid":"782b81b2-5b7e-4f69-9e3e-bf5deed7e4d1"}}}}
{"t":{"$date":"2021-06-10T14:22:06.586+00:00"},"s":"I", "c":"INDEX", "id":20345, "ctx":"initandlisten","msg":"Index build: done building","attr":{"buildUUID":null,"namespace":"admin.system.version","index":"_id_","commitTimestamp":{"$timestamp":{"t":0,"i":0}}}}
{"t":{"$date":"2021-06-10T14:22:06.587+00:00"},"s":"I", "c":"COMMAND", "id":20459, "ctx":"initandlisten","msg":"Setting featureCompatibilityVersion","attr":{"newVersion":"4.4"}}
{"t":{"$date":"2021-06-10T14:22:06.587+00:00"},"s":"I", "c":"STORAGE", "id":20536, "ctx":"initandlisten","msg":"Flow Control is enabled on this deployment"}
{"t":{"$date":"2021-06-10T14:22:06.588+00:00"},"s":"I", "c":"STORAGE", "id":20320, "ctx":"initandlisten","msg":"createCollection","attr":{"namespace":"local.startup_log","uuidDisposition":"generated","uuid":{"uuid":{"$uuid":"874aa57e-a309-4546-a090-7a6a1602f4e0"}},"options":{"capped":true,"size":10485760}}}
{"t":{"$date":"2021-06-10T14:22:06.599+00:00"},"s":"I", "c":"INDEX", "id":20345, "ctx":"initandlisten","msg":"Index build: done building","attr":{"buildUUID":null,"namespace":"local.startup_log","index":"_id_","commitTimestamp":{"$timestamp":{"t":0,"i":0}}}}
{"t":{"$date":"2021-06-10T14:22:06.599+00:00"},"s":"I", "c":"FTDC", "id":20625, "ctx":"initandlisten","msg":"Initializing full-time diagnostic data capture","attr":{"dataDirectory":"/data/db/diagnostic.data"}}
{"t":{"$date":"2021-06-10T14:22:06.601+00:00"},"s":"I", "c":"STORAGE", "id":20320, "ctx":"LogicalSessionCacheRefresh","msg":"createCollection","attr":{"namespace":"config.system.sessions","uuidDisposition":"generated","uuid":{"uuid":{"$uuid":"ddd2219d-532c-46db-90a2-c2e01492632f"}},"options":{}}}
{"t":{"$date":"2021-06-10T14:22:06.602+00:00"},"s":"I", "c":"CONTROL", "id":20712, "ctx":"LogicalSessionCacheReap","msg":"Sessions collection is not set up; waiting until next sessions reap interval","attr":{"error":"NamespaceNotFound: config.system.sessions does not exist"}}
{"t":{"$date":"2021-06-10T14:22:06.602+00:00"},"s":"I", "c":"NETWORK", "id":23015, "ctx":"listener","msg":"Listening on","attr":{"address":"/tmp/mongodb-27017.sock"}}
{"t":{"$date":"2021-06-10T14:22:06.602+00:00"},"s":"I", "c":"NETWORK", "id":23015, "ctx":"listener","msg":"Listening on","attr":{"address":"0.0.0.0"}}
{"t":{"$date":"2021-06-10T14:22:06.603+00:00"},"s":"I", "c":"NETWORK", "id":23016, "ctx":"listener","msg":"Waiting for connections","attr":{"port":27017,"ssl":"off"}}
{"t":{"$date":"2021-06-10T14:22:06.614+00:00"},"s":"I", "c":"INDEX", "id":20345, "ctx":"LogicalSessionCacheRefresh","msg":"Index build: done building","attr":{"buildUUID":null,"namespace":"config.system.sessions","index":"_id_","commitTimestamp":{"$timestamp":{"t":0,"i":0}}}}
{"t":{"$date":"2021-06-10T14:22:06.614+00:00"},"s":"I", "c":"INDEX", "id":20345, "ctx":"LogicalSessionCacheRefresh","msg":"Index build: done building","attr":{"buildUUID":null,"namespace":"config.system.sessions","index":"lsidTTLIndex","commitTimestamp":{"$timestamp":{"t":0,"i":0}}}}
{"t":{"$date":"2021-06-10T14:23:06.579+00:00"},"s":"I", "c":"STORAGE", "id":22430, "ctx":"WTCheckpointThread","msg":"WiredTiger message","attr":{"message":"[1623334986:579376][1:0x7fc320582700], WT_SESSION.checkpoint: [WT_VERB_CHECKPOINT_PROGRESS] saving checkpoint snapshot min: 34, snapshot max: 34 snapshot count: 0, oldest timestamp: (0, 0) , meta checkpoint timestamp: (0, 0)"}}
mongodb의 로그가 찍혀있는 것을 볼 수 있다.
» kubectl get pod
NAME READY STATUS RESTARTS AGE
mongo-depl-5fd6b7d4b4-tvzt6 1/1 Running 0 2m28s
nginx-depl-7fc44fc5d4-wmh8z 1/1 Running 0 6m54s
» kubectl exec -it mongo-depl-5fd6b7d4b4-tvzt6 -- bin/bash
root@mongo-depl-5fd6b7d4b4-tvzt6:/#
root@mongo-depl-5fd6b7d4b4-tvzt6:/# ls
bin boot data dev docker-entrypoint-initdb.d etc home js-yaml.js lib lib64 media mnt opt proc root run sbin srv sys tmp usr var
root@mongo-depl-5fd6b7d4b4-tvzt6:/# exit
exit
mongodb 컨테이너의 bash에 접근했다.
deployment 삭제
» kubectl get deployment
NAME READY UP-TO-DATE AVAILABLE AGE
mongo-depl 1/1 1 1 5m25s
nginx-depl 1/1 1 1 18m
~
» kubectl get pod
NAME READY STATUS RESTARTS AGE
mongo-depl-5fd6b7d4b4-tvzt6 1/1 Running 0 5m29s
nginx-depl-7fc44fc5d4-wmh8z 1/1 Running 0 9m55s
~
» kubectl delete deployment mongo-depl
deployment.apps "mongo-depl" deleted
~
» kubectl get pod
NAME READY STATUS RESTARTS AGE
nginx-depl-7fc44fc5d4-wmh8z 1/1 Running 0 10m
~
» kubectl get replicaset
NAME DESIRED CURRENT READY AGE
nginx-depl-5c8bf76b5b 0 0 0 19m
nginx-depl-7fc44fc5d4 1 1 1 10m
앞서서 bash 명령어로 deployment를 만드는 것을 살펴보았다. 그러나 이런 명령어를 일일이 써서 만드는 것은 굉장히 번거로우므로, 일반적으로는 설정파일을 통해서 만들게 된다.
apiVersion: apps/v1
kind: Deployment # 만들려고 하는 것
metadata:
name: nginx-deployment # 이름
labels:
app: nginx
spec:
replicas: 1 # 레플리카 갯수
selector:
matchLabels:
app: nginx
template: # blueprint
metadata:
labels:
app: nginx
spec: # pod와 관련된 내용
containers:
- name: nginx
image: nginx:1.16
ports:
- containerPort: 80
» kubectl apply -f nginx-deployment.yaml
deployment.apps/nginx-deployment created
» kubectl get pod
NAME READY STATUS RESTARTS AGE
nginx-deployment-644599b9c9-qt6xv 1/1 Running 0 27s
» kubectl get deployment
NAME READY UP-TO-DATE AVAILABLE AGE
nginx-deployment 1/1 1 1 39s
파일에서 replica를 2개로 늘리고 다시 적용해보자.
» kubectl apply -f nginx-deployment.yaml
deployment.apps/nginx-deployment configured
» kubectl get deployment
NAME READY UP-TO-DATE AVAILABLE AGE
nginx-deployment 2/2 2 2 85s
» kubectl get pod
NAME READY STATUS RESTARTS AGE
nginx-deployment-644599b9c9-qt6xv 1/1 Running 0 94s
nginx-deployment-644599b9c9-wjgbt 1/1 Running 0 38s
» kubectl get replicaset
NAME DESIRED CURRENT READY AGE
nginx-deployment-644599b9c9 2 2 2 109s
요약
-
deployment 생성:
kubectl create deployment [name] -
deployment 수정:
kubectl edit deployment [name] -
deployment 삭제:
kubectl delete deployment [name] -
각 종 상태보는 명령어 :
kubectl get nodes | pod | services | replicaset | deployment -
로그 보기:
kubectl logs [pod name] -
pod 터미널 들어가기:
kubectl exec -it [pod name] -- bin/bash -
pod 정보 보기: `kubectl describe pod [pod name]
-
설정파일 적용하기:
kubectl apply -f [filename] -
설정파일 삭제하기:
kubectl delete -f [filename]
